Jet Spray Short Pattern Nozzle, D05A-LA


Product Ref: NDA050002

Estimated Lead time:5 - 7 working days

Home Delivery

UK mainland delivery from £27.50 ex VAT

check delivery cost

Product Description

D05A-LA Jet/Spray Short Pattern Nozzle

The DO5 Industrial range of fire nozzles are manufactured in Light Alloy providing a lightweight branch that remains durable and strong to withstand the demands of heavy industrial use. These fire nozzles will deliver jet and spray patterns simply by gripping the rubber bumper ring and rotating the barrel through JET and SPRAY to a wide angle WATER CURTAIN at full rotation. The bumper ring also provides protection against damage should the branch be dropped on a hard surface such as a concrete floor.

The Water Curtain facility provides rapid cooling of overheated storage tanks etc and enhanced personal protection for the firefighter. The DO5A Fire Nozzles are supplied with a 2" Male Instantaneous inlet fitting. Alongside general firefighting the Delta DO5 fire nozzles are perfect for wash-down, dust suppression and general purpose use. A gunmetal version of the DO5 is available for Delt''s marine customers and can be seen in MARINE NOZZLES.
Models: DO5A

Key Users

  • Major Industry
  • Major Utilities
  • General Users

Key Facts

  • Jet / Spray Nozzle
  • Water Curtain Facility
  • Lightweight

Water Curtain- l/min8 Bar 726
Spray- l/min 8 Bar 544
Jet- l/min 8 Bar 363

Water Curtain- l/min7 Bar 529
Spray- l/min 7 Bar 415
Jet- l/min 7 Bar 333

Water Curtain- l/min6 Bar 511
Spray- l/min 6 Bar 397
Jet- l/min 6 Bar 322



All Jet Spray nozzles are for delivery by customer offload. This entails the customer to acquire the right manpower and/or machinery to help unload the tank/s from the delivery vehicle.

If you require assistance with offloading, we may be able to offer a tail lift (lowers the tank to the ground) or HIAB (lorry with a mounted crane to winch the tank off the delivery vehicle). Please contact us if this is required for delivery.


Our shipping costs cover most of the UK - however, parts of England, Scottish Highlands and Islands including areas north of the Glasgow / Edinburgh border, Isle of Wight, Channel Islands, Isle of Man, Anglesey, Western Isles, Shetland Islands, Orkney Islands, Isles of Scilly, Northern Ireland and the Republic of Ireland may cost more.

Please call before ordering if the delivery postcode is listed below. There may be additional shipping costs. AB, BT, CA, CT, DD, DG, EH, FK, G, GY, IM, IV, JE, KA, KW, KY, LD, LL, ML, PA, PH, PO 30-41 (Isle of Wight), SA, SY, TD, TN, TR, ZE Southern Ireland

Our lead times should only be used as a guide and are subject to change.


Unless a hi-ab delivery has been booked at additional cost, it is the customer's responsibility to offload with suitable equipment on the day of delivery and a failed delivery may result in additional charges.

We recommend installers and/or plant hire & materials to install such as excavators, aggregates etc are not booked until you are in receipt of the goods. Tanks Direct cannot be held responsible for costs incurred due to unforeseen delays, please see our terms for more details.


HIAB delivery will be required if you need the tank offloaded from the delivery vehicle. The driver will unload the tank from the vehicle to ground level, however this service is not to place the tank in situ, this will need to be arranged separately.

If you have any questions regarding your delivery, please contact the Sales Team on 01643 703358.
