GRP Booster Enclosure PWH-1x1x1.5

GRP Booster Enclosure PWH-1x1x1.5

Product Ref: PWH1501

Customer Offloading GRP Rectangle Made to Order, Non Returnable Product Made to Order, Non Returnable Product
  • Dimensions: L:1175mm W:1175mm H:1530mm
  • Estimated Lead time:10 - 14 working days

    Home Delivery

    UK mainland delivery from £88.00 ex VAT

    check delivery cost

    Choose option:

    from £1,250.00 ex VAT
    (£1,500.00 inc VAT)
    Downloadable documents

    pdfPWH1501 Data Sheet

    Product Description

    GRP Booster Enclosure PWH - 1x1x1.5

    Our GRP enclosures are suitable for the protection of a number of items of industrial equipment, including our own water storage tanks, pump sets, valves in fact there is a housing to suit virtually any industrial product.
    Used by Gas, Water and Electricity providers and local authorities along with the Mechanical services industry and many others.

    General Construction

    Our GRP housings are manufactured from the highest quality GRP materials to withstand the rigours of the harshest weather conditions.

    All enclosures have a tough weather resistant polyester gel coat outer, reinforced with a GRP laminate incorporating an encapsulated polyurethane foam core to provide insulation. External colour options are RAL6005 Green or BS 00A05 Industrial Grey. Other colours are available on request.

    Insulation is 25 mm thick as standard. This can be increased to a maximum of 100 mm for extreme temperature applications.

    Internal finish is a durable polyester gel coat finish in white.

    Configurations start as small as 800 x 200 x 800 mm high, up to infinite size.

    Available as one-piece units for smaller applications or in sections in 500 mm increments in length and width up to a height of 3 metres.

    Door furniture includes stainless steel hinges and fixings, Yale type night latch lock assemblies, External door handles, internal door check straps and stays.


    PWH1501 Dimensions

       L x W x H (mm)
     Internal Dimensions  1000 x 1000 x 1500
     External Dimensions  1175 x 1175 x 1530
     Door Configuration  Single 800 x 1300 high opening
     Internal Plu mounting Board  Included 600 x 1220 high

    Product range

    • Smaller GRP enclosures are available as a single piece unit, which are normally delivered to site palletised and only require fixing down to a structural slab or raised kerbing.
    • Larger enclosures are constructed in a metric modular format and can be assembled at our works for delivery as a single unit or, where access restrictions apply, be supplied in sections to allow assembly on site.
    • On site assembly is carried out by our own, directly employed engineers. Purewater do not use subcontract labour for enclosure assembly.



    • Encapsulated ply backing boards for electrical components and switchgear.
    • Tubular heaters and thermostats for frost protection.
    • Bulkhead lighting c/w switch.
    • Screened spill over screens to the housing walls (to comply with water regulations, back flow prevention).
    • Factory prepared pad areas to allow for pipework to pass through housing walls.
    • Single or double door assemblies.
    •  Access man ways to housing roof for applications where space restrictions apply.


    Please contact us and let us know the size of the GRP housing or enclosure required along with any site specific details, such as access restrictions which may apply and we will be happy to provide a detailed quotation.



    All our GRP tanks are for delivery by customer offload. This entails the customer to acquire the right manpower and/or machinery to help unload the tank/s from the delivery vehicle.

    If you require assistance with offloading, we may be able to offer a tail lift (lowers the tank to the ground) or HIAB (lorry with a mounted crane to winch the tank off the delivery vehicle). Please contact us if this is required for delivery.


    Our shipping costs cover most of the UK - however, parts of England, Scottish Highlands and Islands including areas north of the Glasgow / Edinburgh border, Isle of Wight, Channel Islands, Isle of Man, Anglesey, Western Isles, Shetland Islands, Orkney Islands, Isles of Scilly, Northern Ireland and the Republic of Ireland may cost more.

    Please call before ordering if the delivery postcode is listed below. There may be additional shipping costs. AB, BT, CA, CT, DD, DG, EH, FK,G, GY, IM, IV, JE, KA, KW, KY, LD, LL, ML, PA, PH, PO 30-41 (Isle of Wight), SA, SY, TD, TN, TR, ZE Southern Ireland

    Our lead times should only be used as a guide and are subject to change.


    Unless a hi-ab delivery has been booked at additional cost, it is the customer's responsibility to offload with suitable equipment on the day of delivery and a failed delivery may result in additional charges.

    We recommend installers and/or plant hire & materials for install such as excavators, aggregates etc are not booked until you are in receipt of the goods. Tanks Direct cannot be held responsible for costs incurred due to unforeseen delays, please see our terms for more details.

    If you have any questions regarding your delivery please contact the Sales Team on 01643 703358.

    Returns Information

    Customers may return items within 14 calendar days (as per our Terms & Conditions) - refer to section 7. **

    Please be aware that returning a tank can be complicated and expensive so please check that you are ordering the correct item (we suggest checking the dimensions very carefully).

    If you wish to return goods, please complete the form on this page to provide further information.

    Once your request is approved, a valid Returns Authorisation Number (RAN) will be issued to initiate the returns process along with information on how & where to return your order along with any costs involved.

    Please DO NOT return any goods without this authorisation. Goods cannot be accepted without this.

    Returns are not accepted at our Minehead Office, please wait until we contact you before returning any goods.

    Please click here to request a return

    Product Specification

    • Product Code: PW
    • Customer Offloading: Customer Offloading
    • Material: GRP
    • Shape: Rectangle
    • Stock tank: Made to Order, Non Returnable Product
