SECOH JDK-S-60 Single Series Blower Complete with Cable

The SECOH JDK-S-60 is a linear-diaphragm (electromagnetic oscillation) air blower, designed as a modern, energy-efficient replacement for older EL/LP/HP-60 models.

It is engineered for continuous duty aeration service in wastewater treatment, sewage systems, and other applications where dependable, oil-free air supply is needed.

The JDK models are a direct replacement of the Secoh EL series of blower. They feature up to 30% less energy consumption, as well as being more compact than the EL series.

This model is to be used in the Biosafe/ CLP6 unit, located on the inside of the unit.



Features	Benefits
Energy-efficient design	Consumes less power (up to ~30% less than comparable older EL Series) thanks to reduced Internal friction and optimised electromagnetic drive
Compact, Lightweight construction	Smaller footprint and lower weight (6.5 kg) make it easier to install or retrofit in constrained plant enclosures
Oil-Free Airflow	No oil lubrication is needed, so the delivered air is clean and free of oil vapour or contaminants - critical for water/ biozones
Low noise & low vibration	The unit features a built-in muffler chamber and vibration isolation between motor and pump parts to reduce acoustic disturbance
Pulsation-Free flow	Specially shaped pump chambers and muffling result in a smoother, steadier airflow, better suited for fine diffuser systems
Robust, weather - resistant housing	The blower is rated as rainproof / weatherproof (but should be sheltered from direct sun, rain, snow)
Modular Serviceability	Standard spare kits (diaphragms, valve boxes, filters) are available and easy to replace, minimising downtime



APPLICATIONS

• Water treatment
• Ponds & Domestic applications
• Medical and health technology
• Aeration of fuel cell stacks
• Aqua-air-lights and design pillars

Technical:

• Max Flow: 60 Litres per Minute
• Optimal Operating Pressure: 0.20 Bar
• Connector Size: 19mm
• Sound level (at 1.5m): 38dB
• Voltage: 230 VAC

Please note: The Secoh S-series air blowers come with a standard EU plug, these can be removed without effecting warranty
