SECOH JDK-S-80 Single Series Blower

The JDK models are a direct replacement of the EL series of blower - these also feature up to 30% less energy consumption, as well as being more compact than the EL series.

A compact, high-efficiency linear diaphragm air pump engineered especially for aeration applications in wastewater and sewage treatment systems. It replaces the older EL-series models and delivers up to 30% lower energy consumption, with a more compact footprint -making it a compelling upgrade in both performance and cost of operation.

Key Features and Benefits

• Linear Diaphragm (oil free design) - Delivers dry, uncontaminated airflow and eliminates oil contamination risks in your aeration system.
• Electromagnetic Oscillation (Minimal Mechanical Friction) - Reduces internal heating and mechanical wear, thereby increasing diaphragm lifespan and lowering maintenance intervals.
• Low Energy Consumption (= 30% less vs EL Series) - Cuts operating costs by reducing power draw, especially in systems running 24/7
• Compact and Lightweight Footprint - Easier to install in tight plant rooms or in existing blower housings without major system changes
• Low Noise & Vibration - Integrated muffler chambers and vibration isolators minimise acoustic disturbance and mechanical vibration, supporting quieter operation (<43 dB).
• Weather and Rain Resistant housing - Rugged build for outdoor installation (with caveats - not to be directly exposed to extreme elements)
• Simple Maintenance & Spare Parts Support - Uses standard service kits and modular parts, easing upkeep and reducing downtime.

APPLICATIONS

• Water treatment
• Ponds & Domestic applications
• Medical and health technology
• Aeration of fuel cell stacks
• Aqua-air-lights and design pillars

In sewage or wastewater systems, the role of the JDK-S-80 is to generate a steady stream of air (oxygen) that is introduced (via diffusers or air stones) into the liquid/ biological zone. This oxygen supports the aerobic digestion of organic matter by bacteria, which is a key step in reducing biological oxygen demand (BOD), ammonia oxidation, and nitrification.

Technical:

• Max Flow: 75 Litres per Minute
• Optimal Operating Pressure: 0.20 Bar
• Connector Size: 19mm
• Sound level (at 1.5m): 40dB
• Voltage: 230 VAC

Please note: The Secoh S-Series air blowers come with a standard EU plug, these can be removed without effecting warranty
