Kingspan - High Oil Outdoor Alarm


Product Ref: 0017020

1-3 Working Days Delivery

Home Delivery

UK mainland delivery from £6.50 ex VAT

check delivery cost

Product Description

Kingspan - High Oil Outdoor Alarm

The Kingspan separator Oil alarm is powered by mains & is supplied with a control unit and a Conductivity probe.

You can monitor up to 3 probe units, and the outlet relay enables the status of each unit to be signalled to a remote location of your choosing. The alarm can be installed up to 300m from the control panel (Cabling will need to be purchased separately)


  • Control Panel (230v)
  • Probe with 5m fly lead


  • Receive warnings of Oil within the separator
  • Reduces site waste-management costs and ongoing servicing costs
  • Complies with EN858-1&2 and PPG3
  • Can be fitted to separators from all manufacturers


  • Mains Powered: 230AC
  • IP65 ABS Enclosure: 180 x 180 x 60mm
  • Output: Clean Contact Relay
  • Display: Liquid Crystal
  • Alarm: Audible (Local)
  • Probe Range: 200 metres max. (Dependent on cable style)
  • Atex approved: Baseefa 08ATEX0110/1
  • Specific Marking of Explosion Protection: EX II (1) G [Ex ia Ga] IIC (-2°C ≤ Ta ≤ +50°C)

       Compatible probe types:

  • High Oil: Conductivity or specific gravity
  • High Liquid: Optical or float switch
  • Silt: Optical
