Clearwater BioAir CW2 Sewage Treatment Plant - 6 Person

Clearwater BioAir Datasheet

Clearwater BioAir 2 Pumped (6PE) Sales Drawing

Clearwater BioAir 2 & 3 Installation Manual

Clearwater BioAir 2 Gravity (6PE) Sales Drawing

Clearwater BioAir CW2 Sewage Treatment Plant - 6 Person

Available as Gravity or Pumped outlet options, the new Clearwater CW2 BioAir sewage treatment plant employs aerated technology, delivering a high level of water discharge quality.

With adaptable installation choices to accommodate diverse domestic locations and a discreet visual profile, the Clearwater BioAir stands as a financially sensible option for your household wastewater treatment needs.

Product Benefits:

• Affordable
• Suitable for shallow dig Installations
• Flexible installation & lightweight robust design
• Low impact visual footprint
• Supplied with isolator switch and failure light (High Level Alarm optional on IPS unit)
• 1-year warranty* (terms apply)

Typical Applications

• Single & Multiple Homes
• Barn Conversions
• Small Offices
• Farms

MAXIMUM INLET INVERT USING:

Gravity Units: Max Invert: 1400mm      Pumped Units: Max Invert: 1000mm

For Inverts from 755 - 1200mm, order 1 X BPAEXT13

For Inverts from 1200 - 1400mm, order 2 X BPAEXT13

*Please click on the following link to register your warranty.

https://www.kingspan.com/gb/en-gb/products/wastewater-management/guarantee

Commissioning

*Please note that additional commissioning costs may apply for certain Scottish Postcodes. These charges reflect the additional logistics required for servicing these areas. To confirm if your location incurs additional fees, please contact our customer service team for further information.

Commissioning prices apply at the time of purchasing the tank. Additional commissioning charges will apply if purchased separately from the tank.

Delivery

All our Clearwater tanks are for delivery by customer offload. This entails the customer to acquire the right manpower and/or machinery to help unload the tank/s from the delivery vehicle.

If you require assistance with offloading, we may be able to offer a tail lift (lowers the tank to the ground) or HIAB (lorry with a mounted crane to winch the tank off to the nearest hardstanding area only, at an additional cost). Please contact us if this is required for delivery.

• Product Code: CLW
• Customer Offloading: Customer Offloading
• Delivery: Fast Delivery
• Diameter: 1540mm
• Free Site Survey: Free Site Survey
• HIAB Available: HIAB Available
• Material: MDPE
• Stock tank: Stock tank
• Tank Use: Below Ground, Sewage

To ensure your system operates to maximum efficiency, we recommend tried and tested Commissioning by our own British Water and Safe Building trained engineers.

Our unrivalled knowledge means that we are best placed to carry out bespoke assessments to get your system up and running. The commissioning will also provide you with a unique checklist against your system, ensuring your complete peace of mind and reassurance that your system's mechanical and electrical components are in good working order.

The checks below will be carried out by a Kingspan Service Engineer and will only be checked if the unit has been installed in line with the provided installation guidelines.

• Check Plant is level, 5 mm tolerance
• Confirm the ground around the plant is level, flat and that the lid securely fastens
• Confirm the panel has been mounted correctly
• Make the required connections to the panel using correct glands
• Make all electrical connections within the tank
• Ensure all safety guards are fitted
• Set all greasomatics within the plant (if applicable)
• Check belt/chain tension and alignment
• Check pump float activates freely (pumped discharge only)
• Check operation of sludge return pump (nitrification plants only)
• Check direction of disc pack
• Check levels within unit
• Test and set any Alarms supplied with the unit

On completion, they will provide a site specific commissioning certificate

Find out more about what's included in the commissioning of your Clearwater sewage treatment plant and arrange Commissioning, read Kingspan's dedicated guide to Commissioning today.
