2600 Litre Underground water tank

2600 Litre Underground water tank

Product Code: G2600TD

* Required Fields

Exc. Vat £395.00 £474.00 Inc. Vat
- +
Exc. Vat £395.00 £474.00 Inc. Vat

Shipping From £135 (£162 Inc Vat)

(Certain postcodes in Wales, Scotland, Highlands and Islands may cost more,
CLICK HERE for details)

Product Details

2600 Litre Underground water tank

UK Manufactured,
Made from high strength PE, Rota-moulded-single piece, Concrete backfill not usually required

A “fitted” tank means the pipe-work (calmed inlet, filter and connectors) within the tank and spigot connections are pre-installed. The telescopic lid (aka neck & lid) are normally separated to avoid damage during transport. It’s a push fit job to get it to fit onto the tank neck. There is a rubber seal towards the bottom, which ensures a tight fit. The telescopic part is then pulled up to the required level and the backfill supports this extension. It is also good practice to run a bead of silicon around the inside, where the upper part slides over the lower part.

Designed for all standard in-tank filters. Polyethylene underground water harvesting tanks for use in industrial, commercial and domestic schemes. Suitable for Potable or non potable water. The tanks are manufactured in the UK and are available in a wide range of sizes. Made from virgin polymer. This range of UK-Manufactured underground water tanks has been scientifically designed to maximise strength whilst minimising their carbon footprint. The water tanks are suitable for any application that calls for underground storage of water or other non-corrosive liquids. Tanks are rotary moulded from high-quality polyethylene in the UK, minimising their transportation environmental impact. Tanks are designed so that they typically reduce the depth of dig by around 500mm compared to their conventional equivalents.

Options and Accessories
Telescopic neck and 600mm diameter dome
The telescopic neck 520mm - 820mm (can be extended by up to 300mm) and can be tilted in any direction by up to 5 degrees.
All tank sizes come with at least one generously sized 600mm diameter tank dome designed to take a range of filter and pump configurations.

*Deliveries please note it is the customers responsibility to ensure safe, adequate access, turning space and provide their own off loading facilities. Off loading of heavy items should be made by fork lift or similar heavy lifting equipment. If there is any doubt about delivery access or off loading please contact us to discuss the options available.*

Downloads

Product Attachments

View FileVolume Filter VF1    Size: (140.88 KB)

Data Sheet

View File3P Compact Filter    Size: (156.88 KB)

Data Sheet

View File3P Zisternen Filter    Size: (128.33 KB)

Data Sheet

View FileTelescopic Neck for Underground Tanks    Size: (112.21 KB)

Data Sheet

View FileUnderground Tanks    Size: (633.79 KB)

Installation Guide

Shipping Estimate

Estimate Shipping

To use the shipping estimator please select the * Required Fields (if applicable) shown on product above, then enter the quantity required (below) to obtain a carriage estimate.



Please call us for delivery to postcodes in Wales, Scotland, Highlands and Islands.






Specification

Product Code: G2600TD
Height (mm): 1725
Length (mm): 2880
Width (mm): 1260
Capacity (Litres): 2600
Capacity (Gallons): 570
Weight (Kg): 120.00
Shape: Flat/Cylindrical
Material: MDPE
Potable: Potable
Tank Use: Below Ground
SKU: G2600TD

Height shown includes turret (475mm)
Delivery within 5 to 7 days.
