Booster Set -2 1/2" Triple Pump - Multistage Variable Pump Booster
The Tanks Direct triple pump constant pressure cold water booster set, is designed to increase the pressure of water services within a building where the existing incoming main is not sufficient. If the supply of water fails during operation the pumps automatically shuts down to prevent damage and re-starts again once water is restored. The pressure boosters are suitable for private water supply applications, particularly where constant pressure is required or where there are large fluctuations in demand.
• 304 Stainless steel WRAS approved pumps
• BMS Volt Free Contacts
• Variable speed inverter
• Dry run protection
• PWB 8 litres WRAS approved pressure vessel
• Glycerine filled pressure gauge
• Tested and programmed prior dispatch
• Stainless steel Fittings
• Available in twin and single set options
Option: Stainless steel inlet & outlet flexible connector, (recommended over rigid pipe when installing tank away from booster set)
Tanks Direct also supply variable domestic & commercial single and triple pumps, please contact us on 01643 703358.
To use the shipping estimator please select the * Required Fields (if applicable) shown on product above, then enter the quantity required (below) to obtain a carriage estimate.
Please call us for delivery to postcodes in Wales, Scotland, Highlands and Islands.
Full WRAS approved pumps
Supply Voltage: 230v – 1ph – 50hz
Motor P2 (kw): 3 x 1.30
Inlet: 2 1/2"
Typical mid curve duty: 300 l/min @ 4.5 Bar
Full Load Current: 24 amps
