Water level Gauge

Water level Gauge

Product Ref: 801040

  • Weight: 0.010kg
  • Estimated Lead time:3 - 5 working days

    Home Delivery

    UK mainland delivery from £15.00 ex VAT

    check delivery cost

    £46.00 ex VAT
    (£55.20 inc VAT)
    Product Description

    A universal water level gauge, indicating water height between 100cm and 270cm.  Quality level gauge for rain water tanks. Intended for outdoor use on stationary open vented tanks. UV-resistant and pressure-tight meter head. Flange mounting and 1 1/2' BSP connection. Graduated in CM.

    The Movements of the floater are transmitted by a high grade line to the measuring mechanism inside the meter head. The measuring mechanism consists of a spring-loaded winding drum controlling the pointer needle via a gear drive.


    - Meter head ? 110mm in high quality UV-resistant plastic .

    Pressure-tight meter head

    Corrosion-resistant measuring mechanism in acetal plastic and spring motor made of stainless steel.

    Durable float of solid polyethylene.

    can be easily adjusted to the desired tank height by using a screwdriver.

    Mounts with ?100mm mounting flange (4 self tapping screws and gasket included) or 1 1/2' BSP connection.

    Meter head operating temperature range: -30/+50?C.

    Graduated in cm.

    Measuring accuracy: ± 3% of full scale value.
