Sewage Pumping Station, Single Pump, 3500 litre tank

Sewage Pumping Station, Single Pump, 3500 litre tank

Product Ref: MAXIS50VP6H3500

MDPE Sewage
  • Volume: 3500ltr
  • Weight: 3.800kg
  • Dimensions: H:2000mm
  • Diameter: 1500mm
  • Estimated Lead time:1 - 2 working days, 10m Head current lead time 10-14 Working days

    Home Delivery

    UK mainland delivery from £135.00 ex VAT

    check delivery cost

    Choose option:

    updown
    from £1,493.00 ex VAT
    (£1,791.60 inc VAT)
    You may also need:
    Double Door Kiosk
    Double Door Kiosk
    £832.00 ex VAT
    (£998.40 inc VAT)
    Kiosk Single Door
    Kiosk Single Door
    from £409.00 ex VAT
    (£490.80 inc VAT)
    Product Description

    Sewage Pumping Station 3500 Litre - Single Rigged -800/1200/1700 -Package Sewage Pumping Station

    A packaged pump station is used when gravity drainage on site cannot be achieved. The waste from the site flows into an underground storage chamber, where it is then pumped to the main sewer. Packaged pump stations can be used for both foul water (sewage) and surface water applications. Our packaged pump station systems are designed to have a 24 hour storage capacity and are manufactured to BSEN752-6 standards. The Single Rigged 800/1200/1700 Pump Station is suitable for a domestic sewage pumping station for use in areas where gravity flow is not available. It can be used for various drainage applications, with the system also used for the transfer of sewage or waste water, all specially designed for easy installation.

    The Single Rigged 800/1200/1700 is a compact sewage pump station suitable for small to large houses and also commercial applications. The Single Rigged 800/1200/1700 is particularly suitable when water or sewage is collected lower than the main sewer or a septic tank system. All you need is supplied to you within the package, so you will just need to supply the pipework to and from the station, plus any fittings. A high water alarm is available if required. The Pumping Station comes with a submersible pump with 50mm solid handling for peace of mind. Our range of pumping stations is of a superior design and quality, to meet with BSEN75.6 requirements.

    Pump:
    Cast iron/stainless steel construction
    50mm (2") solids handling capacity
    Coolant filled motor
    Mechanical seal
    10 M cable
    Max 6 M lift
    Max flow 5 L/sec
    Float switch as standard
    1 x 10M float controls
    1 x float bracket

    Optional Extra: High level alarm

    Tank:
    Polyethylene tank.
    Dim: 1.0M² x 1.0M D/1.0M² x 1.5M D/
    1.0M x 2.0M D
    Capacity 800/1200/1700L
    1 x 110mm/160mm inlet seal to allow inlet to be drilled on site.
    40mm cable duct.
    2" internal pipe work
    2" non-return valve
    2" quick release coupling
    2" cable duct
    Special audible/visual high level alarm control box available.

    Delivery

    Our shipping costs cover most of the UK - however, parts of England, Scottish Highlands and Islands including areas north of the Glasgow / Edinburgh border, Isle of Wight, Channel Islands, Isle of Man, Anglesey, Western Isles, Shetland Islands, Orkney Islands, Isles of Scilly, Northern Ireland and the Republic of Ireland may cost more.

    Please call before ordering if the delivery postcode is listed below. There may be additional shipping costs. AB, BT, CA, CT, DD, DG, EH, FK,G, GY, IM, IV, JE, KA, KW, KY, LD, LL, ML, PA, PH, PO 30-41 (Isle of Wight), SA, SY, TD, TN, TR, ZE Southern Ireland

    Our lead times should only be used as a guide and are subject to change.

    Offloading

    Unless a hi-ab delivery has been booked at additional cost, it is the customer's responsibility to offload with suitable equipment on the day of delivery and a failed delivery may result in additional charges.

    We recommend installers and/or plant hire & materials for install such as excavators, aggregates etc are not booked until you are in receipt of the goods. Tanks Direct cannot be held responsible for costs incurred due to unforeseen delays, please see our terms for more details.

    If you have any questions regarding your delivery please contact the Sales Team on 01643 703358.

    Returns Information

    Customers may return items within 14 calendar days (as per our Terms & Conditions) - refer to 4.6 & 4.7. **

    Please be aware that returning a tank can be complicated and expensive so please check that you are ordering the correct item (we suggest checking the dimensions very carefully).

    If you wish to return goods, please complete the form on this page to provide further information.

    Once your request is approved, a valid Returns Authorisation Number (RAN) will be issued to initiate the returns process along with information on how & where to return your order along with any costs involved.

    Please DO NOT return any goods without this authorisation. Goods cannot be accepted without this.

    Returns are not accepted at our Minehead Office, please wait until we contact you before returning any goods.

    Please click here to request a return

    Product Specification

    • Product Code: DPT
    • Colour: Black
    • Diameter: 1500mm
    • Material: MDPE
    • Tank Use: Sewage
    • Twin or Single: Single
