Water Meter WRAS 3/4' with 1:1 Pulse Reader
Water Meter WRAS 3/4' with 1:1 Pulse Reader
Product Ref: 20WWM

Available
Water Meter WRAS 3/4'' with 1:1 Pulse Reader
The 3/4' WRAS Water Meter is for measuring the flow and volume of water with a temperature up to 30 ºC on a maximum working pressure up to 16 bar. It is suitable for installation in the horizontal pipelines with the counter directed upwards and in vertical pipelines with the counter directed sidewards. The water meters are equipped with a low eight-barrel counter (IP65), antimagnetic protection SN+ and brass housing.
- Resistant to strong external magnetic fields
- Double-sided rotor bearing
- Readings reliability, fulfils the newest metrological requirements of MID
- Protection which limits the result of water freezing
- The outlet port on the water meter housing is suitable for the optional installation of a return valve
- Clear visual display of the water meter counter
- Hermetic counter is resistant to steaming
- Rotation angle of more the 360º and protection against mechanical tampering
Delivery
Our shipping costs cover most of the UK - however, parts of England, Scottish Highlands and Islands including areas north of the Glasgow / Edinburgh border, Isle of Wight, Channel Islands, Isle of Man, Anglesey, Western Isles, Shetland Islands, Orkney Islands, Isles of Scilly, Northern Ireland and the Republic of Ireland may cost more. Please call before ordering if the delivery postcode is listed below. There may be additional shipping costs. AB, BT, CA, CT, DD, DG, EH, FK,G, GY, IM, IV, JE, KA, KW, KY, LD, LL, ML, PA, PH, PO 30-41 (Isle of Wight), SA, SY, TD, TN, TR, ZE Southern IrelandProduct Specification
- Product Code: ENV
- Diameter: 72
- Potable: WRAS Approved
- WRAS: Yes
- WRAS Approved: Yes
- Weight: 0.010kg
- Dimensions: D:130mm H:68.5mm
