Clearwater E25 Sewage Treatment System - 25 Person



Product Ref: E025G10A0B

Customer Offloading Free Delivery HIAB Available Below Ground, Sewage Below Ground, Sewage
  • Weight: 445.000kg
  • Dimensions: H:2600mm
  • Diameter: 2700mm
  • Request a quote

    Do you require commissioning?

    To ensure your system operates to maximum efficiency, we recommend tried and tested Commissioning by our own British Water and Safe Building trained engineers.
    Our unrivalled knowledge means that we are best placed to carry out bespoke assessments to get your system up and running. The commissioning will also provide you with a unique checklist against your system, ensuring your complete peace of mind and reassurance that your system's mechanical and electrical components are in good working order.

    The checks below will be carried out by a Kingspan Service Engineer and will only be checked if the unit has been installed in line with the provided installation guidelines.

    • Check Plant is level, 5 mm tolerance
    • Confirm the ground around the plant is level, flat and that the lid securely fastens
    • Confirm the panel has been mounted correctly
    • Connect the multi-plug connector to the panel and ensure it is secure
    • Check the air blower is secure and inlet filter fitted
    • Make the final electrical connections to the blower
    • Make sure there is adequate clean air supply into the kiosk
    • Within the tank, check all electrical connections to the internal junction box
    • Connect all airlines and set the valves
    • Make sure BioZones have adequate air supply and even distribution is taking place
    • Set the flow for the final feed airlift
    • Check and test the internal Sludge return pump
    • Check and test the internal recirculation pump
    • Test and set any alarms supplied with the unit (PPFDS, high Level Float)


    On completion, they will provide a site specific commissioning certificate

    To find out more about what's included in the Commissioning of your Clearwater product, or to arrange Commissioning, please click here for more information

    Product Description

    25 Person Clearwater Sewage Treatment System

    Clearwater E-Range is a sewage treatment system from Clearwater that's fully compliant with building regulations and certified to EN 12566. The tank will treat effluent from a domestic or commercial property to a certain level as specified and tested under European Performance Standard EN 12566. Tested for pollution removed from effluence, the power used to do this, and the level of maintenance required by this E6 sewage treatment plant, this plant is a cost-effective, low-maintenance solution for off-mains properties.

    Clearwater's treatment plants are ideal for single houses and employ the well proven aerobic biological process for the treatment of sewage.

    Three distinct process stages take place within the single tank:

    First, coarse solids are filtered and retained for gradual breakdown. Then the resulting liquid is continuously distributed over a plastic suspended filter by an integral lift, powered by a remotely sited blower. Finally, the solids are allowed to settle and, under normal domestic conditions, treated water of 20 mg/l BOD, 30 mg/l S.S., 20 mg/l Ammonia can be achieved.


    Benefits:

    • Superior performance rating.
    • Subject to consent and site conditions, the plant can discharge directly to a watercourse.
    • No mechanical or electrical components within the plant - low running and maintenance costs.
    • Low level visibility with a lockable child-proof pedestrian duty cover - safe for children and pets.
    • Controlled ventilation - minimises risk of odour nuisance.
    • Package options to all requirements and needs.
    • Easy to install and maintain with annual desludging.


    Certificated to European Standard EN-12566. In 2005, a new European Performance Standard was introduced. EN-12566 requires manufacturers to submit their product to a testing regime that accurately measures the performance of treatment plants up to 50 population. These tests identify how much pollution the treatment plant removes from the sewage, what level of maintenance is required, and what power is absorbed. By holding EN-12566 certification, the Clearwater treatment plant is approved for an exemption from a permit to discharge under the new EPP2 environmental legislation.
