Klargester BB BioDisc Sewage Treatment Plant up to 12PE*



Product Ref: BBUAGA104

Customer Offloading Free Delivery Free Site Survey HIAB Available Below Ground, Sewage Below Ground, Sewage Klargester 7 Years
  • Weight: 335.000kg, 350.000kg, 405.000kg
  • Dimensions: W:1995mm H:2160mm, W:1995mm H:2460mm, W:1995mm H:2960mm
  • Estimated Lead time 3-5 working days

    Home Delivery

    UK mainland delivery from FREE ex VAT

    check delivery cost

    Choose option:
    Choose option:

    updown
    You may also need:
    Klargester Sample Chamber
    Klargester Sample Chamber
    from £204.00 ex VAT
    (£244.80 inc VAT)

    Video

    Product Description

    Klargester BioDisc BB Sewage Treatment Plant for up to 12PE*

    For Domestic dwellings without access to mains drainage, the Klargester BioDisc provides a reliable, efficient and environmentally safe solution to your sewage disposal needs.

    It is ideal for locations where discharge is to sub-surface irrigation, or to a suitable watercourse where approved by the regulator, and where a septic tank will not meet the required standard.

    The BioDisc is the only packaged Sewage Treatment Plant which utilises the Rotating Biological Contactor technology for small domestic applications. This process offers inherent cost and performance benefits with a low carbon footprint. Where the Klargester Gravity BioDisc demonstrated an efficiency rating equivalent to a performance of 10 mg/l BOD5, 15 mg/l SS and 3.8 mg/l Ammonia.

    Choose from either Gravity or Integral Pumped System (IPS):

    Gravity is the standard option, however where the inlet to the watercourse or soak away is higher than the outlet of the treatment plant you will require the optional Integral Pumped System (IPS) as this will pump the waste water uphill and into your discharge point. The pumped system (IPS) also comes with a high level alarm.

    Klargester BB Tank Features

    • Affordable running costs and maintenance costs
    • Low noise when in operation and odours free - to BS EN13725 standard
    • Suitable for homes with up to 12 people*
    • Low profile covers for minimal visual impact and childproof locks
    • Invert options to match the site
    • Control panel issues an immediate alert when a problem occurs
    • Single phase standard power supply
    • Optional integral pump available
    • CE marked
    • 7 Years Warranty Period*
    • Pumped outlet: 50 mm MDPE compression fitting


    BB Technical Specification

     Model:  BB
     Population Equivalent (Standard Flow):  12*
     Maximum Daily BOD (kg):  0.72
     Maximum Daily Flow (m3):  2.4
     Maximum Daily Ammonia (g NH4):  96
     Diameter (mm):  1995
     Invert Depth Options (mm):  450 / 750 / 1250
     Depth Below Inlet Invert (mm):  1400
     Outlet Invert Depth (mm):  1315
     Overall Height (mm) Depending on Invert:  2160 / 2460 / 2960
     Height to Rim Of Cover (mm) Depending on Invert:  1945 / 2245 / 2745
     Empty Weight (Kg):  310 / 325 / 380
     Standard Power Supply:  1 Phase
     Motor Rating (Watts):  60
     Full Load Current 1 Phase (amps):  0
     Sludge Return Pump Rating (watts):  250

    *Based on residential applications and daily flow rates



    Performance and Compliance

    • Certified to European Standard BS EN 12566 Part 3.

    • Performance certified to achieve 10 mg/l BOD5, 15 mg/l SS and 3.8 mg/l ammonia.

    • Fully marked in line with the CPR 2013.

    For more information regarding the Klargester BioDisc, please click the following link - Klargester BioDisc













    Product Details

    • Product Code: KLA
    • Customer Offloading: Customer Offloading
    • Delivery: Free Delivery
    • Free Site Survey: Free Site Survey
    • HIAB Available: HIAB Available
    • Tank Use: Below Ground, Sewage
    • Warranty: Klargester 7 Years

    Commissioning & Warranty

    To ensure your system operates to maximum efficiency, we recommend tried and tested Commissioning by Kingspan British Water and Safe Building Trained Engineers.

    Kingspan's unrivalled knowledge means that they are best placed to carry out bespoke assessments to ensutre your system is set up and running correctly.

    Commissioning will also provide you with a unique checklist against your system, ensuring your complete peace of mind and reassurance that your system's mechanical and electrical components are in good working order.

    The Standard Commissioning checks listed below, will be carried out by a Kingspan Service Engineer and will only be checked if the unit has been installed in line with the provided installation guidelines.

    • Check Plant is level, 5 mm tolerance
    • Confirm the ground around the plant is level, flat and that the lid securely fastens
    • Confirm the panel has been mounted correctly
    • Make the required connections to the panel using correct glands
    • Make all electrical connections within the tank
    • Ensure all safety guards are fitted
    • Set all greasomatics within the plant (if applicable)
    • Check belt/chain tension and alignment
    • Check pump float activates freely (pumped discharge only)
    • Check operation of sludge return pump (nitrification plants only)
    • Check direction of disc pack
    • Check levels within unit
    • Test and set any Alarms supplied with the unit

    On completion, the Kingspan Service Engineer will provide a site specific commissioning certificate.

    Upgrade to Smart Commissioning

    Smart Commissioning includes the standard commissioning as scope of works, including supplied and fitted (at point of commissioning) Kingspan Smartserv Pro GSM telemetry alarm for complete peace of mind.

    Smartserv alerts both Kingspan and designated contacts.

    Includes 3 years Kingspan monitoring free of charge.

    Find out more about what's included in the commissioning of your Klargester BioDisc and arrange Commissioning, read Kingspan's dedicated guide to Commissioning today.

    Register your Klargester BioDisc Warranty

    Please click on the following link to register your warranty https://www.kingspan.com/gb/en-gb/products/wastewater-management/guarantee

    *Terms and conditions apply



    BioDisc Spare Parts

    Below are just some of the spare parts we offer for the BioDisc, if you require a different part to the ones below, please click here for our full BioDisc spare part range.

    Spares / Model BB BioDisc
    Motor BB BioDisc Motor
    Belt Pre 2006 / Post 2006
    Pulley Top / Bottom
    Bearings Full Bearing Kit
