Klargester BioFicient 1 6 Person Sewage Treatment Plant

Klargester Klargester BioFicient 1 6 Person Sewage Treatment Plant

Klargester BioFicient 1 6 Person Sewage Treatment Plant

Product Ref: BFP1G

available Available (allow 10 Working days for delivery)

from £2,518.00 ex VAT
(£3,021.60 inc VAT)

updown

Product Description

Klargester BioFicient 1 Domestic Sewage Treatment Plant for up to 6 People



The Kingspan Klargester BioFicient treatment plant provides a reliable and effective solution for domestic application without access to mains drainage. The BioFicient is manufactured from high quality Polyethylene and GRP and uses the latest treatment technology to delivery a high level of water discharge quality. Comprising of three treatment zones within a 'Uni-tank' design, the moving aerated media process used is a compact development of the traditional process and provides a more effective and complete means of sewage treatment.



The BioFicient is suitable for shallow dig requirements, with minimal visual impact. Installation is relatively easy, only requiring a small digger due to its lightweight and unique design features, saving on-site time and expenses.



For added peace of mind, we offer an extended warranty period of 3 years* exclusively for the Bioficient (1-5) models. Terms and conditions apply - Click here.


Product Benefits:





  • Suitable for Shallow Dig Installations


  • Robust and Lightweight


  • High Performance, efficient treatment technology


  • Low Power Consumption


  • Minimal Visual impact with a lockable child-proof cover - safe for children and pets.


  • An extension neck is available to allow for deeper installation on difficult sites


  • Modern design makes access fro desludging is easier through the wide neck


  • BioFicient comes fully supplied with control panel, externally sited air blower and loss of pressure alarms as standard


  • Market leading Extended warranty period of 7 years* (terms apply)


  • BS EN 12566 Part 3 tested and approved


  • Industry leading NH4 (ammonia) removal.


  • Fully CE marked in line with CPR 2013.






Do you require Commissioning?


To ensure your system operates to maximum efficiency, we recommend tried and tested Commissioning by our own British Water and Safe Building trained engineers.


Our unrivalled knowledge means that we are best placed to carry out bespoke assessments to get your system up and running. The commissioning will also provide you with a unique checklist against your system, ensuring your complete peace of mind and reassurance that your system's mechanical and electrical components are in good working order.



Whats included in the Commissioning? Click here for more information
The below is carried out out by a Kingspan Service Engineer, and will only be checked if the unit has been installed in line with the provided installation guidelines.



  • Check Plant is level, 5mm tolerance


  • Confirm the ground around the plant is level, flat and that the lid securely fastens


  • Confirm the panel has been mounted correctly


  • Make the required connections to the panel using correct glands


  • Make all electrical connections within the tank


  • Ensure all safety guards are fitted


  • Sat all greasomatics within the plant (if applicable)


  • Check belt/chain tension and alignment


  • Check pump float activates freely (pumped discharge only)


  • Check operation of sludge return pump (nitrification plants only)


  • Check direction of disc pack


  • Check levels within unit


  • Test and set any Alarms supplied with the unit





If the BioFicient/BioTec has been purchased, commissioning includes the above plus:


  • Check the air blower is secure


  • Set forward feed airlift (larger plants)


  • Make sure there is adequate air supply


  • Connect all airlines and set valves


  • Make sure BioZones have adequate air supply


  • Wire and set timer solenoid for sludge return (if applicable)





  • On completion they will provide a site specific commissioning certificate



    Product Specification

    • Product Code: KLA
    • Tank Use: Below Ground
    • Weight: 0.010kg
    • Dimensions: W:1420mm H:2105mm
