5000 Litre Underground Water Tank

5000 Litre Underground Water Tank

Product Code: TS200/5000

- +
Exc. Vat £1,625.00 £1,950.00 Inc. Vat

(Certain postcodes in Wales, Scotland, Highlands and Islands may cost more,
CLICK HERE for details)

Product Details

5000 Litre (1100 Gallon) Underground water tank.

• Stormwater attenuation
• Fire fighting sprinkler reservoirs
• Potable water storage
• Septic/settlement tanks
• Cesspools and silage effluent holding tanks
• Rainwater Storage
• Accidental spillage containment
• Transformer oil dump tanks
• Package pumping chambers

These underground tanks are filament wound by the technically advanced chop hoop filament winding process (patented) which was chosen after careful investigation proved it produced the most desirable GRP underground tanks. This process produces not only circumferential strength as found in helical wound tanks, but also longitudinal strength. The interlaminar shear strength permits tanks to be cut for manholes and pipework without any undue loss in strength.

The manufacturing process is carefully monitored with a digital read out system. Chopping glass, winding glass, the resin-rich inner layer and main laminate resins are kept within specification parameters thus minimising human error. Each tank has a smooth moulded resin-rich corrosion barrier inner layer and an external resin-rich water penetration barrier. These layers can incorporate special resins to meet specific applications where the contents are highly corrosive or a potable water approved resin system is required or where surrounding soil is heavily contaminated.

Quality control procedures require each tank to be carefully inspected and tested. Ultrasonic thickness readings, material content weights, etc are checked and recorded against the tankand#8217s unique serial number. Additional periodic laminate. Testing is carried out by independent testing facilities including stress and strain analysis and also physical property tests to meet specific design criteria. Being manufactured in glass reinforced plastics, underground tanks are light, easy to handle and easy to install. They are not susceptible to rust, exhibit excellent corrosion resistant properties and have a life expectancy in excess of 50 years. The smooth internal moulded finish provides good flow characteristics and enables easy desludging and cleaning operations.


Product Attachments

View FileUnderground GRP Tank Enquiry Form    Size: (71.9 KB)

Please fill in the details and return it to us for an accurate quote

Shipping Estimate

Estimate Shipping

To use the shipping estimator please select the * Required Fields (if applicable) shown on product above, then enter the quantity required (below) to obtain a carriage estimate.


Please call us for delivery to postcodes in Wales, Scotland, Highlands and Islands.


Items you may also be interested in


Product Code: TS200/5000
Length (mm): 4700
Diameter (mm): 1200
Capacity (Litres): 5000
Capacity (Gallons): 1100
Material: GRP
Tank Use: Below Ground
SKU: TS200/5000
Price shown is for non potable option
Please note the above price is a guide only. The actual price will depend on site specifics and application.
Click Here to fill in our online enquiry form (opens in a new window/tab) or download a PDF form from the 'Downloads' tab above.

Non Potable
Access shaft: 600mm Dia. x 300mm high
Inlets / Outlets: 2 x 110mm Dia.
